pressure gageSeries 62000MU 2.5″ Stainless Steel Pressure Gages

The Series 62000MU Gages have dual English/metric scales with ±1.6% full scale accuracy, and are available in 2.5″ dial sizes. The 62000MU gages are designed with 304 stainless steel housing and brass wetted parts, and includes a back u-clamp connection for panel mounting. Units can withstand ambient temperatures up to 140°F (60°C) and process temperatures up to 248°F (120°C). The 62000MU gages may be easily liquid filled in the field without the need for a separate kit.

Downloads: brochure


sgx and sgfSeries SGX & SGF 2.5″ Stainless Steel Low Pressure Gages

The Series SGX/SGF Gages have dual English/metric scales with ±1.6% full scale accuracy. The Series SGX/SGF gages are designed with 304 SS housings and brass or 316 SS wetted parts. Units can withstand ambient temperatures up to 149°F (65°C) and process temperatures up to 212°F (100°C). Available in vacuum, compound and pressures to 235″ w.c. Included on the dial is a convenient zero adjustment screw for easy re-zeroing.

Downloads: brochure


sgd and sgtSeries SGD Gages

The Series SGD/SGT Gages have dual English/metric scales with ±1.6% full scale accuracy. The Series SGD/SGT gages are designed with 304 SS housings and 316 SS or brass wetted parts for excellent chemical compatibility. These gages cover a wide variety of ranges from full vacuum to 15,000 psi. Series SGD/SGT gages may be easily liquid filled in the field without the need for a separate kit. Gages can be mounted in various configurations.

Downloads: brochure




sgs gageSeries SGS Gages

The Series SGS Gages possess dual English/metric scales with 1.6% full scale accuracy. Series SGS gages are designed with 304 SS housing and brass wetted parts. Units can withstand ambient temperatures up to 149°F (65°C) and process temperatures up to 257°F (125°C). These gages may be easily liquid filled in the field without the need for a separate kit. A wide selection of ranges are available from full vacuum, compound to 15,000 psi.

Downloads: brochure


sgl gageSeries SGL Gages

The Series SGL Gages have dual English/metric scales with ±1.0% full scale accuracy. For excellent chemical compatibility, the Series SGL gages are designed with 304 SS housings and 316L SS wetted parts. Units can withstand ambient temperatures up to 149°F (65°C) and process temperatures up to 572°F (300°C). Series SGL gages may be easily liquid filled in the field without the need for a separate kit. A wide selection of ranges are available from full vacuum, compound to 20,000 psi.

Downloads: brochure


levg gageSeries LEVG Gages

The Series LEVG Level Gages possess dual psi and feet of water column scales with 3-2-3% ANSI B40.1 Grade B accuracy. The 3.5″ or 4.5″ LEVG gages are designed with black steel housings with chrome bezels. Wetted parts include a brass socket and phosphor bronze Bourdon tube. Units can withstand temperatures of -50 to 160°F (-45 to 71°C). A wide offering of ranges are available from 15 to 200 psi (34 to 460 ft. of w.c.) making them the perfect choice for monitoring water tank level. A red adjustable set point indicator is included on every dial.

Downloads: brochure


sg3a gageSeries SG3A Sanitary Pressure Gage

The Series SG3A Sanitary Pressure Gage is made to 3-A sanitary standards and offers several size and pressure range options.The Series SG3A Sanitary Pressure Gage is available with 2″, 2-1/2″, 3-1/2″, or 4″ dials with an accuracy of 1.5% and 2% depending on range. The dials of the Series SG3A Sanitary Pressure Gage are available for vacuum, compound and positive pressure applications. The 3/4″, 1-1/2″, or 2″ sanitary fittings of the Series SG3A create a sanitary process connection available on either the back or bottom of the gage. Also available with Glycerin fill.

Downloads: brochure


series 761 and 762Series 761 Stainless Steel Pressure Gages

Series 761 gages may be easily liquid filled in the field without the need for a separate kit. The gage is designed with 316L SS tube and socket for excellent chemical compatibility and are offered in a wide selection of ranges from full vacuum, compound to 20,000 psi.

Downloads: brochure




series 761 and 762Series 762 Pressure Gages

Series 762 gages have a glycerin-filled housing, providing superior performance in applications where vibration, pulsation, mechanical shock and pressure spikes are common. The gage is designed with 316L SS tube and socket for excellent chemical compatibility and are offered in a wide selection of ranges from full vacuum, compound to 20,000 psi.

Downloads: brochure


series 763 pressure gageSeries 763 Pressure Gages

The Series 763 Process Gage uses psi scales with 0.5% full scale ANSI B40.1 Grade 2A accuracy. The 763 gages is designed with a solid Phenolic safety-case with blow-out back. Internal overload and under-load protection is provided to prevent damage to the gage from extreme swings in pressure. Access to the adjustable needle pointer is simple via the removable bezel. Series 763 units are shipped dry, but can be easily liquid-filled in the field without the need for a separate kit.

Downloads: brochure


763 and 764 gageSeries 764 Pressure Gages

The Series 764 Process Gage uses psi scales with 0.5% full scale ANSI B40.1 Grade 2A accuracy. The 763 gages is designed with a solid Phenolic safety-case with blow-out back. Internal overload and under-load protection is provided to prevent damage to the gage from extreme swings in pressure. Access to the adjustable needle pointer is simple via the removable bezel. Series 764 units contain glycerin fill which allows the gages to be used in high vibration applications.

Downloads: brochure


2000 magnehelicSeries 2000 Magnehelic® Differential Pressure Gage

The Magnehelic® gage is highly acccurate –guaranteed within 2% of full scale, with a wide choice of 81 models available to suit your needs precisely. Using Dwyer’s simple, frictionless Magnehelic® gage movement, it quickly indicates low air or non-corrosive gas pressures–either positive, negative (vacuum) or differential. The design resists shock, vibration and over-pressures. No manometer fluid to evaporate, freeze or cause toxic or leveling problems.

Downloads: brochure | manual


4000 capsuhelicSeries 4000 Capsuhelic® Differential Pressure Gage

The Capsuhelic® gage is designed to give fast, accurate indication of differential pressures. Using the basic design of Dwyer’s time-proven Magnehelic® gage, the Capsuhelic® gage contains a simple, frictionless movement that permits full scale readings as low as 0.5 inch water column. The pressure being measured is held within a capsule which is an integral part of the gage. This containment of the pressure permits the use of the gage on system pressures of up to 500 psig, even when differentials to be read are less than 0.1 inch w.c.

Downloads: brochure | manual


2-5000 minihelicSeries 2-5000 Minihelic® II Differential Pressure Gage

Combining clean design, the Minihelic® II gage is designed for panel mounting in a single 2-5/8″ diameter hole. Standard pressure connections are barbed fittings for 3/16″ I.D. tubing; optional 1/8″ male NPT connections are also available. Over-pressure protection is built into the Minihelic® II gage by means of a blow-out membrane molded in conjunction with the diaphragm. Accidental over-ranging up to the rated total pressure will not damage the gage. With removable lens and rear housing, the gage may be easily serviced at minimum cost. The 5% accuracy and low cost of the Minihelic® II gage make it well-suited for a wide variety of OEM and user applications.

Downloads: brochure | manual


differential pressure pistonSeries PTGA Differential Pressure Piston-Type Gage

The Series PTGA contains a piston-sensing element, which provides differential pressure ranges from 0-150 psid through 0-400 psid with full-scale accuracies of ±3-2-3%. Constructed from aluminum or 316 Stainless Steel and available with two 1/4″ female NPT end connections, the Series PTGA provides overrange protection rated to 5000 psig (340 bar).

Downloads: brochure | manual




ptgb pressure pistonSeries PTGB Differential Pressure Piston-Type Gage

The Series PTGB Differential Pressure Piston-Type Gage is a low cost differential pressure gage used to measure the pressure drop across filters, strainers, pump performance testing, and heat exchanger pressure drop monitoring. Its simple, rugged and compact design possesses a weather and corrosion resistant gage front with a shatter resistant lens. The Series PTGB contains a piston-sensing element, which provides differential pressure ranges from 0-10 psid to 0-110 psid with accuracies of ±3-2-3%. Constructed from aluminum or 316 stainless steel and available with two 1/4″ female NPT back or end connections.

Downloads: brochure | manual


ptgc pressure pistonSeries PTGC Differential Pressure Piston-Type Gage

The Series PTGC Differential Pressure Piston-Type Gage has a simple and rugged design with weather and corrosion resistance and a shatter resistant lens. The Series PTGC contains a piston-sensing element, which provides differential pressure ranges from 0-10 psid to 0-110 psid with full-scale accuracies of ±5%. Constructed from aluminum with internal materials made up of 316 stainless steel and available with two 1/4″ female NPT end connections, the Series PTGC provides over-range protection rated to 5000 psig (340 bar).

Downloads: brochure | manual


dpga and dpgw gagesSeries DPGA & DPGW Digital Pressure Gages

The Series DPGA is the only economic digital pressure gage with selectable engineering units on the market. With its 1% accuracy and digital push-button zero, the DPGA is the perfect choice for digitally monitoring the pressures of air and compatible gases. The Series DPGW is the only economic digital pressure gage for liquids with the ability to select engineering units on the market. With its 1% accuracy and digital push-button zero, the DPGW is the perfect choice for digitally monitoring the pressures of air and compatible liquids and gases.

Downloads: brochure | manual


626 and 628 transmittersSeries 626-628 Industrial Pressure Transmitters

The Series 626 Pressure Transmitters possess a highly precise 0.25% piezo-resistive sensor contained in a compact, rugged, NEMA 4X stainless steel general purpose housing or cast aluminum conduit housing. The Dwyer Series 628 Pressure Transmitters are ideal for OEMs with 1% full scale accuracy sensors. The transmitter is also available in the general purpose stainless steel housing and the cast aluminum conduit housing.Available in ranges of vacuum, compound to 5000 psi.

Downloads: brochure | manual


pressure transmitterSeries 629 Wet/Wet Differential Pressure Transmitter

The Series 629 Differential Pressure Transmitter monitors differential pressure of air and compatible gases and liquids with 0.5% accuracy. The design employs dual pressure sensors converting pressure changes into a standard 4-20 mA output signal for two wire circuits. Small internal volume and minimum moving parts result in exceptional response and reliability. Terminal block zero and span adjustments are easily accessed under the top cover. The Series 629 Differential Pressure Transmitter is designed to meet NEMA 4X (IP66) construction.

Downloads: brochure | manual


pressure transmitterSeries 647 Wet/Wet Differential Pressure Transmitter

Monitor differential pressure in air/liquid flow systems, HVAC automation, pneumatic systems and process control with the Series 647 Wet/Wet Differential Pressure Transmitter. Units are temperature compensated and provide a 4 to 20 mA output signal which can be interfaced with chart recorders, data loggers and computerized monitoring and control systems.

Downloads: brochure | manual




series rmv flowmasterSeries PBLT Submersible Level Transmitter

PBLT2 and PBLTX Submersible Level Transmitters are manufactured for years of trouble free service in the harshest applications. Both measure the height of liquid above the position in the tank referenced to atmospheric pressure. The transmitter consists of a piezoresistive sensing element, encased in a 316 SS housing. Large diameter 316 SS diaphragm seal is non-clogging and damage resistant to floating solids.Units come equipped with a 270-pound tensile strength shielded and vented cable. Ventilation tube in the cable automatically compensates for changes in atmospheric pressure above the tank. The vent is protected with a maintenance free filter eliminating particulate or water droplets from entering the transducer.

Downloads: brochure | manual


rmv flowmeterSeries RMV Rate-Master® Dial-Type Flowmeter

Series RMV Rate-Master® Flowmeters measure higher water flow rates with ±2% of full scale accuracy at affordable prices. Rugged forged brass housing is standard on all models for great compatibility and the strength to withstand system pressures to 1000 psig (68.9 bar). Unlike glass tube rotameters, these units won’t shatter and they work fine with even dark and/or opaque liquids. Stocked models are fitted with 1″ female NPT inlet and outlet; 3/4″ and 1/2″ sizes are also available. Install in line, supported by piping or flush panel mount with complete hardware package included.

Downloads: Brochure | Manual




rotometersSeries VFA-VFB Rotometer

The Visi–Float® flowmeter bodies are cut and precision machined from solid, clear acrylic plastic blocks. The front scale location and white background provides excellent visibility. The direct reading scales are hot stamped into the plastic and will not wear off. Mid-range calibration is established with a master flowmeter. Accuracy is ±5% of full scale for VFA models, ±3% for VFB. Scales average 2″ long on the VFA models, 4″ long on VFB. Available with either brass or stainless steel inlet and outlet connections tapped for 1/8″ NPT thread. VFB models 85 and 86 have either 1/4″ back or 3/8″ end connections. Precision metering valves in brass or stainless steel are available for most VFA and VFB models.

Downloads: brochure | manual


series uv flowmeterSeries UV Ultra-View™ Polysulfone Flowmeter

Setting a new standard in the industry, the Series UV Polysulfone Flowmeter is an ultra pure, laboratory grade flowmeter (±2% F.S. accuracy) that measures flow in GPM and LPM of water and other compatible media; SCFM and LPM of gas. The Series UV is designed to withstand high temperatures up to 212°F (100°C) and high pressures up to 150 psi (10.34 bar). Highly corrosion-resistant, this instrument is an excellent choice for monitoring many ultra pure applications such as food processing, reverse osmosis water systems, medical equipment and corrosive media. Easy to install and to clean, the Series UV offers optional panel mount polysulfone fittings and a protective polycarbonate shield.

Downloads: brochure | manual


polycarbonate flowmeterSeries LFM Polycarbonate Flowmeter

The New LFM Series Flowmeters are made of injection molded, heat and chemically resistant polycarbonate bodies and fittings. Series LFM flowmeters have dual scales measuring in both GPM and LPM with 5% accuracy. A textured background on the body enhances scale readability. Standard in-line models come with 1/2″ male NPT connections for LFMA, LFMB & LFMC; 3/4″ male NPT connections for LFMD; 1″ male NPT connections for LFME; and 2″ male NPT connections for LFMF. Panel mount installation is available with 90° elbow fittings that include panel lock nuts. Various other fittings are available.

Downloads: brochure | manual


sight flow indicatorsSeries SFI-100/300/350/360/400/700 MIDWEST Sight Flow Indicators

Midwest Sight Flow Indicators are manufactured of quality materials and safety tested to assure long, dependable service at economical prices. Available in window viewing style in the 100 and 300 Series and tube viewing style in the 400 and 700 Series with connection choices of female NPT, BSPP, or BSPT threaded and flanged. Series 700 has impeller and internal wipers for cleaning sight tube, which is perfect for fluids with suspended solids. Just rotate the glass tube and restore full 360° visibility without disrupting the flow.

Downloads: brochure | manual


v4 flotectSeries V4 FLOTECT® Vane Operated Flow Switch

Rugged and reliable the Series V4 Flotect® flow switch operates automatically to protect equipment and pipeline systems against damage from reduction or loss of flow. The V4 is time tested being installed in thousands of pipelines and processing plants around the world. A unique magnetically actuated switching design gives superior performance. There are no bellows, springs, or seals to fail. Instead, a free-swinging vane attracts a magnet within the solid metal switch body, actuating a snap switch by means of a simple lever arm.

Downloads: brochure | manual


v6 flow switchSeries V6 FLOTECT® Mini-Size Flow Switch

The Series V6 Flotect® Flow Switch is engineered to specifically monitor liquid, gas, or airflows. Operation is simple and dependable with no mechanical linkage as the flow switch is magnetically actuated. The lower body holds the flow vane and one magnet, which controls the switch actuating magnet in the separate upper housing. In most applications the switch is normally off with the pipeline flow forcing the vane against the vane spring. As the flow decreases the vane spring pushes back the vane, actuating the switch to signal an alarm or shutdown. Tees are available for installation in pipelines from 1/2″ to 2″, with bushings added the unit is easily adapted to 1/4″ and 3/8″ piping.

Downloads: brochure | manual


v8 flow switchSeries V8 FLOTECT® Vane Operated Flow Switch

The V8 Flotect® Flow Switch has a leak proof body and vane constructed of tough durable polyphenylene sulfide which has excellent chemical resistance. The full size trimmable vane is provided with molded-in graduations allowing for installation in a 1 inch through 6 inch pipe. Operating pressures are up to 150 psig (10 bar) and temperatures to 212°F (100°C). The V8 flow switch can be used in various chemical processes, industrial systems and similar applications where process conditions are compatible with polyphenylene sulfide, ceramic 8 and 316SS. The V8 Flotect® flow switch is UL recognized as an industrial motor controller per UL standard 508, suitable for mounting in a protected environment.

Downloads: brochure | manual


v10 flow switchSeries V10-V11 FLOTECT® Vane Operated Flow Switch

The V10 flow switch utilizes a rugged, hermetically sealed reed switch which is encapsulated in a polypropylene switch housing that fits into a standard heavy duty leak proof brass body or optional 303 Stainless Steel body.The V11 Flotect® flow switch takes the V10 design and adds rugged, integral electrical wiring. The one-piece PBT switch housing snaps onto the body and the wiring is epoxy sealed making the switch weatherproof, meeting NEMA 4 standards. The 22 AWG cable used is UV resistant, flame retardant, and comes standard 6 feet in length.

Downloads: brochure | manual


v12 flow switchSeries V12 FLOTECT® Flow Switch

The Series V12 Flotect® Flow Switch is a low cost, versatile line of switches that can be used in a wide range of applications and configurations. Mountable in any orientation, the Series V12 Flow Switch utilizes a free moving shuttle that is displaced by the liquid flow, activating an isolated, sealed reed switch. Models can be used in media that is compatible with PPE & PS, stainless steel and ceramic 1. FDA approved materials option has wetted materials of stainless steel and FEP.

Downloads: brochure | manual


adjustable flow switchSeries AFS Adjustable Flow Switch

The Series AFS Adjustable Flow Switch is externally adjustable and is ideal for protecting machine tools from coolant flow failure, protecting bearings from loss of lubricant or assuring proper air flow. The Series AFS offers an infinite number of flow settings at pressures up to 1000 psig, with low pressure drop and precise repeatability. The AFS is housed in either brass or stainless steel and can be used with water, compatible liquids, oils, and gases.

Downloads: brochure | manual


vane flow switchSeries FS-2 Vane Flow Switch

Direct-Reading Series FS Flowmeters offer visual flow rate indication and an adjustable flow alarm to close AC electrical circuits, trigger warning lights, or activate other process control equipment. Spring-retained moveable piston design allows installation in any position.

Downloads: brochure | manual




tds flow switchSeries TDS Thermal Dispersion Flow Switch

The Series TDS Thermal Dispersion Flow Switch offers solid state flow detection of non-coating liquids for pump and process protection. SPDT output allows for interfacing with remote PLC or relay control device. The adjustable switch point is factory calibrated at 0.2 fps with LED indication of flow and calibration status. Units feature selectable NO or NC operation and are not damaged by overranging flow velocities.

Downloads: brochure | manual


series hiflow valvesSeries HiFLow Valves

W.E. Anderson Hi-Flow™ control valves are single seated, top or cage guided globe valves – probably the simplest, from construction standpoint, yet most versatile control valve in The Hi-Flow™ control valve can fit applications with a smaller size since the valve has a greater flow capacity than most conventional valves of the same size.Coupled with the high flow capacity, the Hi-Flow™ control valve maintains a wide rangeability of 50:1 to insure precise control. Heavy duty Hi-Flow™ control valves are ruggedly constructed of the highest quality materials, precision machined, and performance tested to assure years of trouble free service. Standard packing consists of PTFE V-rings and wiper to minimize friction without leakage at high operating pressures. Available in brass, iron, 316 SS body, trim is 316 SS with all welded plug construction provide superior durability and corrosion resistance.

Downloads: brochure


abv automated valvesSeries ABV Automated Two-Piece Brass Ball Valve

The ABV Series is an economical automated valve package with either an electric or pneumatic actuator. Electric actuated models are weatherproof, NEMA 4, powered by standard 115 VAC supply, and are available in either two-position or proportional control. Two-position actuators use the 115 VAC input to drive the valve open or closed, while the modulating actuator accepts a 4 to 20 mA input for infinite valve positioning. Actuator features thermal overload protection and a permanently lubricated gear train. The pneumatic double acting actuator uses an air supply to drive the valve open and closed. The actuator has two supply ports with one driving the valve open and the other driving the valve closed. Spring return pneumatic actuator uses the air supply to open the valve and internally loaded springs return the valve to the closed position.

Downloads: brochure | manual


automated ball valveSeries BV2-F1 Automated Ball Valve – Two-Piece SS Flange

The Series BV2-F1 ball valves offer ANSI 150# flanged ends for easy installation. 1/2″ through 4″ sizes are standard for great flow rates with minimal pressure drop. The valve features a blowout-proof stem for added safety, reinforced PTFE seats and seals for longer life, and a 316 Stainless Steel (ASTM A351 GR CF8M) ball for better performance. Actuators are direct mounted, creating a compact assembly for tight spaces. Double o-ring stem seals assure leak-free operations.

Downloads: brochure | manual


automated ball valvesSeries 3BV3 Automated Ball Valve – 3-Way SS NPT

The 3BV3 is an economical automated valve package with either an electric or pneumatic actuator. Electrically actuated models are weatherproof, NEMA 4, powered by standard 115 VAC supply, and are available in either two-position or proportional control. Two-position actuators use the 115 VAC input to drive each of the valve ports open or closed, while the modulating actuator accepts a 4 to 20 mA input for infinite valve positioning.The pneumatic double acting actuator uses an air supply to drive each of the actuator ports. Spring return pneumatic actuators use the air supply to drive the valve stem one direction, and internally loaded springs return the valve to its original position.

Downloads: brochure | manual


automated ball valveSeries 3ABV Automated Ball Valve – 3-Way Brass NPT

The Series 3ABV is an economical automated valve package with either an electric or pneumatic actuator. Electrically actuated models are weatherproof, NEMA 4, powered by standard 115 VAC supply, and are available in either two-position or proportional control. Two-position actuators use the 115 VAC input to drive each of the valve ports open or closed, while the modulating actuator accepts a 4-20 mA input for infinite valve positioning.

The pneumatic double acting actuator uses an air supply to drive each of the actuator ports. Spring return pneumatic actuators use the air supply to drive the valve stem one direction, and internally loaded springs return the valve to its original position.

Downloads: brochure | manual


npt steel ball valveSeries BV3_NPT Three-Piece Stainless Steel Ball Valve

The BV3 Series is an economical automated valve package with either an electric or pneumatic actuator. Electrically actuated models are weatherproof, NEMA 4, powered by standard 115 VAC supply, and are available in either two-position or proportional control. Two-position actuators use the 115 VAC input to drive the valve open or closed, while the modulating actuator accepts a 4 to 20 mA input for infinite valve positioning.

The pneumatic double acting actuator uses an air supply to drive the valve open and closed. The actuator has two supply ports with one driving the valve open and other driving the valve closed. Spring return pneumatic actuators use the air supply to open the valve and internally loaded springs return the valve to the closed position.

Downloads: brochure | manual


stainless steel ball valveSeries BV2 Two-Piece Stainless Steel Ball Valve

The Series BV2M is the economical choice for high quality, stainless steel ball valves for use in chemical, petrochemical, pulp and paper and general applications. The Series BV2M body and endcaps are constructed of investment cast stainless steel, while stem is 316SS. Seats and body seals are 15% glass reinforced TFE providing broad media compatibility and bubble tight shutoff to 1000 psig (69 bar). Internally loaded, blowout-proof stem provides safety in the event of overpressure. Full port design allows for maximum Cv with minimal pressure drop. Integral actuator mounting pads allows for ease of automation.

Downloads: brochure | manual


hand leverSeries BV2M Two-Piece Hand Lever Brass Ball Valve

The Series BV2MB is an economical hand lever ball valve for commercial and general industrial use. The Series BV2MB is perfect for as a manual shutoff valve for hot and cold water systems. Valve body, body cap, and ball are made of quality brass. Seats and stem packing are constructed of TFE for long lasting service. Blowout-proof stem provides safety in the event of overpressure. Full port design allows for maximum Cv and minimal pressure drop.

Downloads: brochure | manual


3 piece ball valveSeries 2BVS Three-Piece Stainless Steel Ball Valve

The Series 2BVS is an economical, stainless steel, ball valve ideal for chemical, pharmaceutical, and food and beverage applications. Three piece construction allows for in line maintenance and cleaning. Valve body and endcaps are investment cast for exceptional quality and corrosion resistance. Reinforced TFE seats and body seals are glass reinforced for strength while providing excellent chemical compatibility and bubble tight sealing to 1000 psi. Standard ISO 5211 mounting pad allows for easy automation. Full port design provides maximum Cv with minimal pressure drop.

Downloads: brochure | manual


sanitary ball valveSeries BV3HL-3A Three-Piece Sanitary Ball Valve

The Series BV3HL Sanitary Ball Valves feature Sanitary Clamp ends for easy line removal. The sanitary polish is ideal for use in pharmaceutical, food & beverage, and chemical processing systems. PTFE filled cavities aid to reduce product entrapment, while the full bore design provides consistent flow characteristics. This swing-out design of the valve allows for maintenance of the center section while leaving the ends clamped in place. Superior leak protection is accomplished by using a live-loaded packing system. An ISO 5211 mounting pad is provided for easy automation when combined with an electric and pneumatic actuator.

Downloads: brochure | manual


sanitary ball valveSeries BV3HL Three-Piece Sanitary Ball Valve

The Series BV3HL-3A Sanitary Ball Valves are designed to meet 3A standards and feature Sanitary Clamp ends for easy line removal. The sanitary polish is ideal for use in pharmaceutical, food & beverage, and chemical processing systems, while the cavity filler aids to reduce product entrapment, and the full bore design provides consistent flow characteristics. This swing-out design of the valve allows for maintenance of the center section while leaving the ends clamped in place. Superior leak protection is accomplished by using a live-loaded packing system. An ISO 5211 mounting pad is provided for easy automation when combined with an electric and pneumatic actuator.

Downloads: brochure | manual
