Cameron Measurement

Turbine Meters
Flow Analyzers

nuflo turbine familyCAMERON™ Liquid Turbine Meters

NuFlo turbine flowmeters indicate flow rate and measure total throughput of a liquid line. As liquid flows through the meter and over the rotor, the rotor turns at a speed that is directly proportional to the flow rate. A magnetic pickup senses the rotor blades as they pass and generates an electrical (sine wave) signal. These electrical pulses are then transmitted to the flow measurement readout equipment.

Downloads: Brochure | Manual




nuflo turbine familyCAMERON™ EZ-In Turbine Turbine Meters

NuFlo turbine flowmeters indicate flow rate and measure total throughput of a liquid line. As liquid flows through the meter and over the rotor, the rotor turns at a speed that is directly proportional to the flow rate. A magnetic pickup senses the rotor blades as they pass and generates an electrical (sine wave) signal. These electrical pulses are then transmitted to the flow measurement readout equipment.

Downloads: Brochure | Manual




nuflow flow analyzerCAMERON™ MC-II™ Flow Analyzer

The MC-II Flow Analyzer provides separate, continuous digital displays of flow rate and accumulated flow based on input from a turbine flowmeter. The low current consumption of its liquid crystal displays and CMOS microprocessor based circuitry enable years of dependable performance from a single lithium battery. Typical battery life is 3 to 5 years. Totalizer readings can be made in any desired volumetric units, and flow rates can be measured in units per second, minute, hour, or day. Rate and total are quickly and easily calibrated using the keypad on the front of the MC-II. The instrument is suitable for outdoor installation and requires no additional protection from the weather. The unit may be mounted directly on the turbine meter or attached remotely.

Downloads: Brochure | Manual




MC-IIICAMERON™ MC-III™ EXP Flow Analyzer

Cameron’s NUFLO™ MC-III™ EXP Flow Analyzer provides state-of-the-art liquid and gas measurement with data logging and Modbus® communications in an easy-to-use explosion-proof totalizer. The MC-III EXP is designed to preform reliably in hazardous areas and in the harshest environmental conditions across the globe. Users can select a 4 to 20 mA output, a pulse output or an amplified flow meter frequency output that allows remote equipment to calculate flow rates and volume.

Downloads: brochure | manual






MC-III Panel MountCAMERON™MC-III™ Panel Mount Flow Analyzer

Cameron’s NUFLO™ MC-III™ Panel Mount Flow Analyzer provides state-of-the-art liquid and gas measurement with data logging and Modbus® communications in an easy-to-use totalizer with a standard 1/4-DIN mount. With capacity to record up to 384 daily flow logs, 768 hourly logs and 345 event logs, downloadable in less than a minute.

Download: brochure | manual






MC-III WPCAMERON™MC-III™ WP Flow Analyzer

Cameron’s NUFLO™ MC-III™ Panel Mount Flow Analyzer provides state-of-the-art liquid and gas measurement with data logging and Modbus® communications in an easy-to-use weather proof totalizer. Features include direct or remote mount, Easy calibration, and password-protected security.

Download: brochure | manual






nuflo flow analyzerCAMERON™ MC-II™ WP Flow Analyzer – OBSOLETE

The MC-II WP Flow Analyzer is a weatherproof instrument which provides a continuous display of instantaneous flow rate and accumulated total volume of liquid or gas based on a turbine flow meter input signal. It combines ease-of-use and functionality for a truly user friendly flow analyzer.






nuflo flow analyzerCAMERON™ MC-II™ Plus WP Flow Analyzer – OBSOLETE

The MC-II Plus WP Flow Analyzer is a weatherproof instrument which provides a continuous display of instantaneous flow rate and accumulated total volume of liquid or gas based on a turbine flow meter input signal. It combines ease-of-use and functionality for a truly user friendly flow analyzer.






flow analyzer    CAMERON™ MC-RTU Flow Analyzer   OBSOLETE

The MC-RTU flow analyzer provides continuous digital display of flow rate and total flow of liquids or gases. When combined with a NUFLO Turbine flow meter, selected for a particular application, the MC-RTU becomes an accurate flow rate meter and flow totalizer. Low power microprocessor technology provides the MC-RTU with long life and reliability. Easily programmable using the front four-wide keypad, the MC-RTU can be programmed to display a wide variety of total flow and flow rate volumetric units. Two types of packaging and mounting options are available to suit many different applications including outdoor and hazardous locations.
